YK-2500 Mechanical Speed 500 Nails / Minute,4 Servo Motor Semi Auto
Double Pieces Stitching Machine
Description of main parts and functions:
★ Imported four servo control system.
★ One set can be used for single, double and irregular cartons.
★ The size adopts all electric control.
★ Nailable: Single nail, double nail, reinforced nail can be
completed at one time.
★ The paper feeding section automatically counts and the finished
product is sent out for bundling.
★ Suitable for small and medium carton, fast and labor-saving
binding.
★ Adjust the nail distance, use the computer to set the automatic
nail distance.
★ Suitable for small and medium-sized cartons with three or five
layers. Cardboard boxes with bottom and no cover can also be
nailed. Seven layers need to be customized.
★ Stitch distance (small-large) 30mm-120mm can be adjusted
arbitrarily.
★ Mechanical speed: 500 nails / minute
Technical Parameters
Max size(A＋B)×2
| 4200mm |
Min size(A＋B)×2
| 110mm |
Max carton length(mm)A
| 1900mm |
Min carton length(mm)A
| 350mm |
Min carton width B
| 200mm |
Min carton height(C+D+C)
| 300mm |
Power
| 6kw |
Stitching Distance
| 30-120mm |
Speed
| 500-600nail/min |
Nail line
| 17-18 |
Nail number
| 2-99 |
The main parameters
| Power supply system | Computer system | Technical index |
| Servo driver | Mitsubishi | Head | Zhuhai Pushan Machinery Equipment | Speed | 500-600 nail/min |
| Servo motor | Mitsubishi | Pulley | Foshan Yuanmingchuang | Nail pitch accuracy | 1mm |
| PLC | Omron | Head reducer | Shinpo | Start | Photoelectric detection cardboard and foot switch |
| Contactor | Shihlin, Taiwan | Gear reducer | Emerson Taiwan | Mode | Double/Single |
| Relay | Schneider | Belt | Zhejiang Sanwei | Power | 6kw |
| Touch screen | Willunton | | | Weight | 2000kg |
| The electromagnetic valve | Yadek | | | | |
FAQ
1. who are we?
CHINA YIKE GROUP, Which based in Hebei, China, start from 2002,sell
to Mid East(24.00%),South America(21.00%),Eastern
Europe(15.00%),Africa(10.00%),Southeast Asia(10.00%),North
America(5.00%),Western Europe(2.00%),Southern Europe(2.00%),Eastern
Asia(10.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Firstly pre-production sample before mass production;
Secondly Inspection before shipment;
3.what can you buy from us?
Corrugated Cardboard Production Line,Carton Box Making machine, Box
Printing Forming Machine, Auto folder gluer, sitching machine, die
cutting machine, bundling machine..
4. why buy from us not from other suppliers?
Factory related carton machinery import & export company, based on
more than 30 years experience in providing complete and carton
machinery solutions according to different customer situations and
requriements. reliable quality and good service on site.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,DDP,DDU,Express
Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit
Card,PayPal,Western Union,Cash;
Language
Spoken:English,Chinese,Spanish,Portuguese,Arabic,French,Russian,Italian
