1400x2400mm Auto Feeder Chain Feeder 2 Color Printer Slotter Machine From YIKE GROUP

Chain Feed Table Unit:

• Table by a welded steel plate and channel.Table plate thickness:3.7mm.Channel is China's national standard of 10# channel steel.
• Table length 2380mm,4 to 5 groups feed chain.Each chain has three push feeder.
• Configuration 2 side cover.Made with 5# angle iron.
• The forefront of the table with platen spring.Flexographic printer new multicolor semi-automatic letterpress paper printer chain machine.
• Automatic measurement of the number of cardboard.

Printer Unit:

• Gear enclosed spay lubrication system,keyless drive design,so that accurate long-term chromatic unchanged.High-speed ink printing slotting machine manufacture 2.2 frequency control system to control becomes easy and flexible.Each group of printing unit is equipped with jogging button for easy control and loaded rubber plated.
• Each printing unit can be electrical separation.Printing slotting machine.
• High-precision anilox roller,diameter 195mm.The textured density of anilox roller is 180-300 lines/inch,to ensure the printing effect is clear and beautiful.
• Ink supply system is pneumatic diaphragm pumps,high efficiency,flexo printing slotting machine saving ink.Automatic cycle supply.Cleaning with clean water can be 2.6 automatic uniform system to keep the anilox roller quit.When the machine stop,the anilox roller and rubber roller could running independently for transmission ink and prevent.

Slotter Unit:

• Gear enclosed spray lubrication system,keyless drive design,so that accurate long-term chromatic unchanged.High speed flexo printing slotting(stacking unit) 3.2 phase institutions is 360 degree electric adjustment,ergonomin design.
• Four-blade sync adjustment for carton height.
• Serrated slotted cutter.Thickness:7mm.Cutting angle blade width:45mm.

Die Cutter Unit: (OPTION)

• The die-cutting unit depart from the main machine,separate driving(adopts kobe servo controller from German) totally solved the problems of changing printing positing due to the die-cutting rushing.
• Adopt fold type rubber roller,easy to change and convenient operation.Imported rubber roller from Taiwan,the using life is three times of the normal rubber roller.
• Automatic control left and right moving of rubber roller,the scope is 50mm,steady moving and reliable.
• The die-cutting phasing adopts servo control,touch screen adjust and control,can store orders.
• Pneumatic control the gap between the cutter mould roller and the soft roller.

It has speed compensation system,automatic adjust the speed of rubber roller,insure the same size of carton and the cutting dies.
